How is a GPS watch produced?
Date:2019-01-18      Clicks:0
How to define a good GPS watch? You may assume three things, various functions, exquisite appearance and comfortable wearing. In fact, I believe the most important thing for most people is quality, which determines the long-term stable and comfortable experience of using this product. Excellent quality comes from precise production and rigorous quality inspection.


After all the materials are ready, assign different components to different working positions. After the assembly is completed, there will be specialized battery aging test, waterproof test, GSM signal test, etc., ReachFar has special instruments and specialized engineers to test the devices to avoid defective products flowing into the market. Now let’s learn about the production and testing of one of our GPS watch RF-V38.

After all the materials are ready, assign different components to different working positions. After the assembly is completed, there will be specialized battery aging test, waterproof test, GSM signal test, etc., ReachFar has special instruments and specialized engineers to test the devices to avoid defective products flowing into the market. Now let’s learn about the production and testing of one of our GPS watch RF-V38.

Production process of a GPS watch
Prepare main board, welding key FPC, charging interface FPC, microphone, speaker, install GPS antenna, install main board in the housing, waterproof test, install firmware, aging test, GSM and GPS signal test. For details, please refer to the following steps.

1.Assembly: prepare the main board, weld the button FPC, charging interface FPC, microphone, speaker, install GPS antenna, install the display screen, apply waterproof tape, install the back-housing magnet, and install the whole housing. In this process, attention should be paid to the installation position of all the components, the position of the antenna will affect the GPS signal and GSM signal, the screen installation will affect the experience of using the touch screen. The accuracy of the waterproof tape will affect the waterproof level of the device.
2.Waterproof test: RF-V38 is an IP67 product, in order to ensure the waterproof performance of the product, we use the professional instrument to test every product. Pump air into the tracker with waterproof testing instruments, and then inject the test gas. There is no blister in the water tank, then it proves there is no gap in the product. The waterproof performance is very good.
3.Install main firmware: connect the device to the computer, flash the prepared firmware into the device, test the GPS, wi-fi positioning function, keypad function and 3D sensor according to the corresponding operation, and the test results show every function testing are successful, it proves the functional test is successful.
4.Aging test: After assembly and installing main firmware, the device goes into the aging area for aging test. Connect device with charger. The test will last for 8 hours. Observe the device in the charging process, test the stability of the machine, to ensure the stability for the using in the future.
5.GSM signal detection: insert a special testing SIM card into the device and put it on the signal testing instrument. Use the tracker to dial a call out and observe the signal strength value of the device. The signal strength value is 35.26. With the standard value of 30, the signal of the watch means strong.
6.Packing and warehousing: packing all the accessories and the GPS watch. USB magnetic charging cable, user manual and screwdriver shall be put into the packaging box, then store it in the warehouse.
Do you think this is the end?
In fact, after the customer places an order, we need to take the corresponding products out of the warehouse and register the IMEI and ID number of each product into our tracking platform. In this way, you are able to see the real time tracking information of the tracker.
